WL9-6127 Wheeled Protective Case

The interior is 545*545*210 mm and the exterior 610*610*270 mm. A square floor suits panels, control modules and fixtures laid out in rows, because several identical items can sit side by side without the dead space that appears at both ends of a long narrow case. If the equipment needs locating, send the outline dimensions and we will cut foam pockets to match the cavity.

The closed case is rated IP67 for water and dust protection, which covers short immersion, heavy rain and dusty workshops. We do not claim military standard certification for this model. The square lid runs a long sealing path, so check the gasket for marks or trapped debris and close the latches evenly, which is what keeps the rating effective over a long service life.

At 8540 g empty the case already has some weight, and once loaded it is meant to be rolled rather than carried far by hand. Put the heaviest equipment towards the wheel end to lower the centre of gravity, extend the handle fully and start moving gradually. On stairs, ramps or soft ground, lift it with two people so the wheels are not overloaded.

Shell material and wall thickness for this model are confirmed on the drawing issued with each order; ask our sales team for that drawing and the matching test data before you commit. The 610*610*270 mm exterior and 545*545*210 mm interior are the factory figures, so choose the model on internal size and allow extra room for the foam insert inside.

Yes. Kexin New Materials (Guangdong) Co., Ltd. supplies factory-direct from its Zhongshan factory and runs OEM and ODM programmes, so foam inserts, colour, silk-screen printing, nameplates and latch options can all be adjusted. A square cavity works well for divided foam. Send your equipment list and outline sizes, and we will propose a cut layout along with MOQ and lead time.
