How fast can the Protective Case Customization Process deliver?

With an existing tool and a new insert, 30 to 35 days. A new tool needs 55: 18 of tooling, 7 of trials, 12 of production.

Which gate slips most often?

Drawing review. Drawings often lack cavity size and wall thickness, and confirmation takes three to five days.

Are two trial rounds always required?

For a new tool, usually. Fill and distortion first, dimensions and colour second. A simple case can pass in one round.

Can the liner wait until the case is built?

No. The EVA die is cut to the actual cavity, so the liner is frozen five days before production.

What happens if inspection fails?

Critical defects reject the batch. Major defects above AQL 2.5 mean a larger sample or sorting.

Protective Case Customization Process: Six Gates to Shipment

Quick answer: The Protective Case Customization Process runs through six gates: inquiry and requirement lock, drawing review, tooling, trials and first article, production with liner fitting, and inspection before shipment. A typical project takes 55 to 70 days, including 18 to 25 days of tooling and two trial rounds spanning ten days. Each gate ends with a signed output, not a promise.

The Six Gates and the Total Clock
Inquiry and Requirement Lock
Drawing and Structural Review
Tooling, Trials and First Article
Mass Production, Liner Fitting and Shipping Release
FAQ

1. The Six Gates and the Total Clock

The Protective Case Customization Process has six gates, one signatory each: sales signs the requirement, the structural engineer the drawing, the tooling supervisor the trial report, quality the first article, the plant manager release.

Gate	Input	Output	Days	Sign-off
1 Inquiry	Size, liner, volume	Quote, requirement sheet	1–2	Sales lead
2 Drawing	2D drawing or sample	Tool change list	3–5	Engineer
3 Tooling	Tool plan, steel order	Assembled tool	18–25	Tooling lead
4 Trials	Tool, resin, colour chip	Three first articles	7–10	Quality
5 Production	First article, kitted parts	Finished cases	12–15	Planner
6 Inspection	Cases, packing list	Release note	1–2	Quality lead

Gate time totals 42 to 59 days; quotes land at 55 to 70, the gap being steel, trial cooling and queues. Ordering steel on day two overlaps tooling and saves three days, the only slack in the Protective Case Customization Process.

2. Inquiry and Requirement Lock

Inquiry, the first gate of the Protective Case Customization Process, turns a request into quotable terms. Four variables move price: new tool or modified insert, egg-crate foam or cut EVA, volume tier, and standard or custom colour. A new tool costs 18,000 to 35,000 yuan, an insert 3,000 to 6,000, an EVA die 800 to 1,500, and custom colour starts at 200 pieces. The requirement sheet fixes dimensions, liner, colour with a Delta E ceiling, volume split and terms; the sales lead signs.

3. Drawing and Structural Review

Review takes three to five days, the cheapest gate in the Protective Case Customization Process. The engineer checks draft, wall uniformity, rib thickness, hinge boss, rim width and stacking path.

Item	Rule	Cost of ignoring it
Draft angle	At least 1 degree	Scuffing, whitening, sticking
Main wall	2.5 to 4 mm	Sink marks and warp
Rib thickness	0.6 of main wall	Sink on the opposite face
Rim width	12 mm or more	Gasket clashes with latch
Hinge boss	5 mm or more	Screws strip with use

Output is a tool change list: which rib thins, which radius opens, whether the rim gains two millimetres. The engineer signs before steel is ordered.

4. Tooling, Trials and First Article

Tooling takes 18 to 25 days in the Protective Case Customization Process; modifying a tool 5 to 8. Two trial rounds sit three days apart: fill and distortion first, dimensions second. Three first articles are sealed, measured and dropped.

Trial check	Limit	Action if out
Outer size	Plus or minus 2 mm	Rework cavity
Part weight	Within 3 percent	Check melt and shot
Rim flatness	0.5 mm or less	Rework rim insert
Colour	Delta E 1.5 or less	Recheck resin batch
Latch cycle	200 cycles	Rework latch pocket

Release needs every dimension in tolerance and colour within Delta E 1.5. The tooling supervisor and quality signs, and the master sample is kept 12 months for later runs of the Protective Case Customization Process.

5. Mass Production, Liner Fitting and Shipping Release

Production runs 12 to 15 days per 500-piece batch; a projected area above 0.12 square metres needs 800 tonnes. Each shift starts with the master sample, resin drying and mould temperature.

The liner runs in parallel: egg-crate foam in three days, EVA with a two-day die and three days of cutting. Bonding rests four hours before closing, a common rush point in the Protective Case Customization Process. Inspection is booked 48 hours ahead at AQL 2.5.

Conclusion

Six gates work because each hands over a document: requirement sheet, tool change list, three first articles, patrol sheet, release note. Add ten days of buffer to 42 to 59 days and overlap tooling by three, and a 55 to 70 day promise holds. That is how the Protective Case Customization Process stays predictable.

This article discusses only the container (case body) side of specifications and design intent, and does not cover any handling, loading or use of the contents.
